| Model | Output power | Output voltage | Output current | Outline size | Efficiency | Safe approval |
| F-15-12 | 15W | 12V | 1.25A | 142*30*20mm | 82% | CE |
| F-20-12 | 20W | 12V | 1.6A | 181*30*20mm | 82% | CE |
| F-30-12 | 30W | 12V | 2.5A | 221*30*20mm | 83% | CE |
| F-45-12 | 45W | 12V | 3.75A | 251*40*22mm | 82% | CE |
| F-60-12 | 60W | 12V | 5A | 180*72*45mm | 83% | CE |
| F-100-12 | 100W | 12V | 8.3A | 248*72*45mm | 85% | CE |
| Input voltage | 100V-240V | | Lifetime | >3Years |
| Input frequency | 50-60Hz | | Waterproof grade | IP67 |
| In-rush current | Cold boot:230V 20A | | Working temperature | -20℃~+50℃ |
| Power factor | 0.6 | | Storage temperature | -40℃~+85℃ |
| Ripple & Noise | ≤Vout x 1% | | Working relative humidity | 10%-100% |
| Protection | OLP SCP OVP OTP | | Storage relative humidity | 5%-95% |
| Model | Output power | Output voltage | Output current | Outline size | Efficiency | Safe approval |
| F-15-12 | 15W | 12V | 1.25A | 142*30*20mm | 82% | CE |
| F-20-12 | 20W | 12V | 1.6A | 181*30*20mm | 82% | CE |
| F-30-12 | 30W | 12V | 2.5A | 221*30*20mm | 83% | CE |
| F-45-12 | 45W | 12V | 3.75A | 251*40*22mm | 82% | CE |
| F-60-12 | 60W | 12V | 5A | 180*72*45mm | 83% | CE |
| F-100-12 | 100W | 12V | 8.3A | 248*72*45mm | 85% | CE |
| Input voltage | 100V-240V | | Lifetime | >3Years |
| Input frequency | 50-60Hz | | Waterproof grade | IP67 |
| In-rush current | Cold boot:230V 20A | | Working temperature | -20℃~+50℃ |
| Power factor | 0.6 | | Storage temperature | -40℃~+85℃ |
| Ripple & Noise | ≤Vout x 1% | | Working relative humidity | 10%-100% |
| Protection | OLP SCP OVP OTP | | Storage relative humidity | 5%-95% |
