15W/25W/36W/50W/60W/120W
DongDaHua
8504401425
Quantity: | |
---|---|
Model | Output power | Output voltage | Output current | Outline size | Efficiency | Safe approval |
SCE-15-12 | 15W | 12V | 1.25A | 70*39*31mm | 80% | CE |
SCE-25-12 | 25W | 12V | 2.08A | 85*58*38mm | 80% | CE |
SCE-36-12 | 36W | 12V | 3A | 85*58*38mm | 80% | CE |
SCE-50-12 | 50W | 12V | 4.16A | 110*78*35mm | 80% | CE |
SCE-60-12 | 60W | 12V | 5A | 160*98*38mm | 80% | CE |
SCE-120-12 | 120W | 12V | 10A | 199*98*42mm | 80% | CE |
SCE-150-12 | 150W | 12V | 12.5A | 199*98*42mm | 80% | CE |
SCE-200-12 | 200W | 12V | 16.6A | 199*98*42mm | 80% | CE |
SCE-250-12 | 250W | 12V | 20.8A | 200*110*50mm | 80% | CE |
SCE-360-12 | 360W | 12V | 30A | 215*115*50mm | 80% | CE |
SCE-480-12 | 480W | 12V | 40A | 242*125*65mm | 80% | CE |
SCE-600-12 | 600W | 12V | 50A | 242*125*65mm | 80% | CE |
Input voltage | 87V-264V | | Lifetime | >3Years |
Input frequency | 50-60Hz | | Waterproof grade | IP20 |
In-rush current | Cold boot:230V 40A | | Working temperature | -35℃~+55℃ |
Power factor | 0.5 | | Storage temperature | -40℃~+85℃ |
Ripple & Noise | 150mV | | Working relative humidity | 10%-100% |
Protection | OLP SCP OVP OTP | | Storage relative humidity | 5%-95% |
Model | Output power | Output voltage | Output current | Outline size | Efficiency | Safe approval |
SCE-15-12 | 15W | 12V | 1.25A | 70*39*31mm | 80% | CE |
SCE-25-12 | 25W | 12V | 2.08A | 85*58*38mm | 80% | CE |
SCE-36-12 | 36W | 12V | 3A | 85*58*38mm | 80% | CE |
SCE-50-12 | 50W | 12V | 4.16A | 110*78*35mm | 80% | CE |
SCE-60-12 | 60W | 12V | 5A | 160*98*38mm | 80% | CE |
SCE-120-12 | 120W | 12V | 10A | 199*98*42mm | 80% | CE |
SCE-150-12 | 150W | 12V | 12.5A | 199*98*42mm | 80% | CE |
SCE-200-12 | 200W | 12V | 16.6A | 199*98*42mm | 80% | CE |
SCE-250-12 | 250W | 12V | 20.8A | 200*110*50mm | 80% | CE |
SCE-360-12 | 360W | 12V | 30A | 215*115*50mm | 80% | CE |
SCE-480-12 | 480W | 12V | 40A | 242*125*65mm | 80% | CE |
SCE-600-12 | 600W | 12V | 50A | 242*125*65mm | 80% | CE |
Input voltage | 87V-264V | | Lifetime | >3Years |
Input frequency | 50-60Hz | | Waterproof grade | IP20 |
In-rush current | Cold boot:230V 40A | | Working temperature | -35℃~+55℃ |
Power factor | 0.5 | | Storage temperature | -40℃~+85℃ |
Ripple & Noise | 150mV | | Working relative humidity | 10%-100% |
Protection | OLP SCP OVP OTP | | Storage relative humidity | 5%-95% |
